AUDIO FREQUENCY OSCILLATOR

The INTERLABS A.F.OSCILLATOR, Model AFO-1, is a very useful laboratory instrument and is a source of pure sine wave and square waves. It is intended primarily to test, measure audio equipment parameters, such as input sensitivity, frequency response, stage gain, distortion and power.

It can be used to test or service any audio devices, like microphones, loudspeaker, pickups, amplifiers, etc.

It can also be used as a tone generator and to modulate RF signals. The square waves are intended to determine frequency response and harmonic distortion quickly. Square-wave testing of amplifier is a modern and easier method.

This instrument is completely an IC version and generates frequencies, from 2Hz to 200KHZ in five decade ranges. The output voltage can be varied continuously upto 10 volts (peak) Into 150 ohms. The distortion is less than 0.5 percent.
The rise time of the square wave is less than 50 nano seconds. This instrument is housed in a sturdy metal cabinet, which is light in weight,

SPECIFICATIONS
1.WAVE-FORMS GENERATED
SINE AND SQUARE WAVES.

2. FREQUENCY RANGE:
Continuously variable from 1Hz to 100KHz in five decade ranges of:

3. OUTPUT VOLTAGE:
Variable upto (10V peak) into 50-ohms load. The output is short circuit. protected, Voltage multiplier from (0-1)V and (1- 10)V is provided.

4. DISTORTION:
Less than 0.5 percent,

5.RISE TIME OF SQUARE WAVES:
Less than 50 nano seconds.

6. CIRCUITRY
Completely IC version.

7. HOUSING:
Elegant cabinet fitted with one handle for portability.

8. Dimension:
25.5cms x 12cms x 14cms

9. Weight:
(Approx.) 500GMS

10. Power:
230 VAC – Mains operated
